Development of an encapsulation process for toxic waste and hazardous chemicals in a fluidized bed

Objectives. This paper presents research results on the encapsulation of a fluidized bed of liquid and solid toxic waste containing chemicals with a hazard class of 1–3.
Methods. Soils contaminated with hexachlorobenzene and hexachlorocyclohexane were used as the seed material. Ceresin was selected as the encapsulant, which was sprayed onto the fluidized bed through a pneumatic nozzle at a temperature of 135°C. Before the spraying of the ceresin, binders were introduced into the fluidized bed of the seed material through pneumatic nozzles in the form of a melt of high-temperature coal-tar pitch and wastewater containing sodium and arsenic salts as well as heavy metal oxides. The experiments were carried out using a modified GLATT AGT-150 laboratory unit.
Results. The results demonstrate that the mechanism for granule formation is a mixed mechanism. The binding of the seed material is carried out by both the pitch and salting out. In this case, the cavities in the agglomerates are partially filled with salt deposits, which increases the strength and integrity of the final product’s structure. Ranges for the process parameter values were established at the point at which there was no unwanted agglomeration in the fluidized bed, and dust formation did not exceed 5%. When the ratio of the bed mass to the mass of ceresin is equal to unity, a moisture-resistant free-flowing product of hazard class 5 is obtained, which is suitable for transportation and long-term storage. The average diameters of the initial particles and encapsulated granules were 0.5 and 1.5 mm, respectively.
Conclusions. The present study demonstrates a potential process for the granulation– encapsulation of toxic waste and hazardous substances with a hazard class of 1–3 in a single fluid-bed apparatus, resulting in the formation of a moisture-resistant hazard class-5 granular product suitable for transportation and long-term storage. The results obtained can be used in the development of an industrial large-scale process for encapsulating waste of hazard classes 1–3.

1. Jiang X., Li Y., Yan J. Hazardous waste incineration in a rotary kiln: a review. Waste Dispos. Sustain. Energy. 2019;1(1):3–37. https://doi.org/10.1007/s42768-019-00001-3

2. Block C., Van Caneghem J., Van Brecht A., et al. Incineration of Hazardous Waste: A Sustainable Process? Waste Biomass Valor. 2015;6(2):137–145. https://doi.org/10.1007/s12649-014-9334-3

3. Sheu E.Y., Mullins O.C. (Eds.). Asphaltenes: fundamentals and applications. New York: Springer; 1995. 258 p. https://doi.org/10.1007/978-1-4757-9293-5

4. Spence R.D., Shi C. (Eds.). Stabilization and Solidification of Hazardous, Radioactive, and Mixed Wastes. Boca Raton: CRC Press; 2005. 391 p.

5. Leist M., Casey R.J., Caridi D. The fixation and leaching of cement stabilized arsenic. Waste Manag. 2003;23(4):353–359. https://doi.org/10.1016/S0956-053X(02)00116-2

6. Clancy T.M., Snyder K.V., Reddy R., Lanzirotti A., Amrose S.E., Raskin L., et al. Evaluating the cement stabilization of arsenic-bearing iron wastes from drinking water treatment. J. Hazard. Mater. 2015;300:522–529. https://doi.org/10.1016/j.jhazmat.2015.07.051

7. Shon J.S., Lee S.H., Kim G.N., Kim I.T., Shin H.S. Effect of Polyethylene as Additive on the Bituminized Waste Form with Hazardous Ash Waste. Environ. Technol. 2000;21(4):407–415. https://doi.org/10.1080/09593332108618100

8. Brandt H.C.A., De Groot P.C. Aqueous leaching of polycyclic aromatic hydrocarbons from bitumen and asphalt. Wat. Res. 2001;35(17):4200–4207. https://doi.org/10.1016/S0043-1354(01)00216-0

9. Шахова Н.А. Конструирование и расчет аппаратов с псевдоожиженным слоем: учеб. пособие. М.: МИХМ; 1978. 83 с. [Shahova N.A. Konstruirovanie i raschet apparatov s psevdoozhizhennym sloem: Uchebnoe posobie (Design and calculation of fluidized bed apparatuses: Tutorial). Moscow: MIHM; 1978. 83 p. (in Russ.).]

10. Parikh D.M. Handbook of Pharmaceutical Granulation Technology: 2nd ed. Boca Raton: Taylor & Francis Group; 2005. 654 p.

11. Елеев Ю.А., Глухан Е.Н., Казаков П.В., Беликов В.А. Особенности масштабирования процесса сушки-грануляции в псевдоожиженном слое в условиях принципиальных конструкционных различий натурной и модельной установок. Хим. Пром. Cегодня. 2016;6:34–44. [Eleev Yu.A., Glukhan E.N., Kazakov P.V., Belikov V.A. Features of the fluidized bed granulation scale-up process under the fundamental structural differences between model and industrial units. Khim. Prom. Segodnya (Chem. Ind. Today). 2016;6:34–44 (in Russ.).]

12. Schæfer T., Wørts O. Control of fluidized bed granulation. III. Effects of inlet air temperature and liquid flow rate on granule size and size distribution. Control of moisture content of granules in the drying phase. Arch. Pharm. Chem. Sci. 1978;6:1–13.

13. Smith P.G. Applications of fluidization to food processing. Oxford: Blackwell; 2007. 258 p.

14. Masters K. Spray Drying: An Introduction to Principles Operational Practice and Applications. London: Leonard Hill Books; 1972. 668 p.

15. Knight P.C. An investigation of the kinetics of granulation using a high shear mixer. Powder Technol. 1993;77(2):159–169. https://doi.org/10.1016/0032-5910(93)80053-D

16. Dencs B., Ormós Z. Particle formation from solution in a gas fluidized bed. I. Powder Technol. 1982;31(1):85–91. https://doi.org/10.1016/0032-5910(82)80007-7

17. Crooks M.J., Schade H.W. Fluidized bed granulation of a microdose pharmaceutical powder. Powder Technol. 1978;19(1):103–108. https://doi.org/10.1016/0032-5910(78)80077-1

18. Waldie B. Growth mechanism and the dependence of granule size on drop size in fluidized-bed granulation. Chem. Eng. Sci. 1991;46(11):2781–2785. https://doi.org/10.1016/0009-2509(91)85147-P

19. Bayvel L., Orzechowski Z. Liquid Atomization. Washington: Taylor & Francis; 1993. 477 p.

20. Hemati M., Cherif R., Saleh K., Pont V. Fluidized bed coating and granulation: influence of process-related variables and physicochemical properties on the growth kinetics. Powder Technol. 2003;130(1–3):18–34. https://doi.org/10.1016/S0032-5910(02)00221-8

21. Shornikova O.N., Malakho A.P., Govorov A.V., Galiguzov A.A., Nashchokin A.V., Avdeev V.V. Wetting of Carbon Fibers by Coal-Tar Pitch Melts. Fibre Chem. 2016;47(5):367–371. https://doi.org/10.1007/s10692-016-9694-5
