Quantitation of polysorbate 80 in recombinant protein formulation using high-performance liquid chromatography

Objectives. Polysorbate 80 (PS80) quantification in biopharmaceutical products has always been challenging owing to its minute content, absorption to the protein backbone, lack of specific chromophoric PS80 groups, and heterogenic nature. This work is aimed at developing an express method for PS80 analysis in biopharmaceutical products using hydrolysis and subsequent highperformance liquid chromatography analysis with ultraviolet detection that does not consume substantial amounts of sample (≥35 μL).

Methods. Five therapeutic protein formulations were chosen as model proteins. Alkaline hydrolysis formulation was applied, without protein precipitation and with a range of precipitation techniques to remove protein from the test solution and hydrolyze PS80, to free fatty acids. The obtained hydrolysate was analyzed using reverse-phase high-performance liquid chromatography.

Results. As a result of the high protein content of monoclonal antibody formulations, preliminary protein removal was required, which was achieved by precipitation with organic solvents. A specific precipitant ethanol–isopropanol mixture (1:1 volumetric ratio) was developed to efficiently remove antibodies while keeping PS80 in the solution. The PS80 quantification method was developed for monoclonal antibody drugs. For three monoclonal antibody drug products (adalimumab, infliximab, and eculizumab), method validation was performed according to the International Council for Harmonization of Technical Requirements for Pharmaceuticals for Human Use, the United States Pharmacopeia, and the State Pharmacopeia of the Russian Federation guidelines.

Conclusions. The optimal assay conditions for each group of recombinant monoclonal antibody substances were chosen. Protein precipitation with ethanol or ethanol–isopropanol mixtures before hydrolysis was introduced, allowing for a substantial reduction of sample to 35 μL or even less if PS80 content is higher than 0.05 mg/mL. Accelerated hydrolysis (90 min) is preferable to slow hydrolysis (4–18 h). Method validation for protein products such as adalimumab, infliximab, and eculizumab was demonstrated for the first time. Both methods were validated for each drug product. The coefficients of variation for method specificity and high precision were ≤6.0% for 3 analyses. The accuracy of the methods ranged from 96% to 109% for all of the tested drug products.

1. Pinholt C., Hartvig R.A., Medlicott N.J., Jorgensen L. The importance of interfaces in protein drug delivery– why is protein adsorption of interest in pharmaceutical formulations? Expert Opin. Drug Deliv. 2011;8(7):949–964. https://doi.org/10.1517/17425247.2011.577062

2. Singh S.M., Bandi S., Jones D.N.M., Mallela K.M.G. Effect of Polysorbate 20 and Polysorbate 80 on the HigherOrder Structure of a Monoclonal Antibody and Its Fab and Fc Fragments Probed Using 2D Nuclear Magnetic Resonance Spectroscopy. J. Pharm. Sci. 2017;106(12):3486–3498. https://doi.org/10.1016/j.xphs.2017.08.011

3. Crommelin D.J.A., Hawe A., Jiskoot W. Formulation of Biologics Including Biopharmaceutical Considerations (2011) In: Crommelin D.J.A., Sindelar R., Meibohm B. (Eds.). Pharmaceutical Biotechnology. Springer; 2019. P. 83–103. https://doi.org/10.1007/978-3-030-00710-2_5

4. Agarkhed M., O’Dell C., Hsieh M.C., Zhang J., Goldstein J., Srivastava A. Effect of Surfactants on Mechanical, Thermal, and Photostability of a Monoclonal Antibody. AAPS Pharm. Sci. Tech. 2018;19:79–92. https://doi.org/10.1208/s12249-017-0845-7

5. Wang W., Wang Y.J., Wang D.Q. Dual effects of Tween 80 on protein stability. Int. J. Pharm. 2008;347(1–2):31–38. https://doi.org/10.1016/j.ijpharm.2007.06.042

6. Hillgren A., Lindgren J., Aldén M. Protection mechanism of Tween 80 during freeze-thawing of a model protein, LDH. Int. J. Pharm. 2002;237(1–2):57–69. https://doi.org/10.1016/s0378-5173(02)00021-2

7. Larson N.R., Wei Y., Prajapati I., et al. Comparison of Polysorbate 80 Hydrolysis and Oxidation on the Aggregation of a Monoclonal Antibody. J. Pharm. Sci. 2020;109(1):633–639. https://doi.org/10.1016/j.xphs.2019.10.069

8. Lippold S., Koshari S.H.S., Kopf R., Schuller R., Buckel T., Zarraga I.E., Koehn H. Impact of mono- and poly-ester fractions on polysorbate quantitation using mixedmode HPLC-CAD/ELSD and the fluorescence micelle assay. J. Pharm. Biomed. Anal. 2017;132:24–34. https://doi.org/10.1016/j.jpba.2016.09.033

9. Ilko D., Braun A., Germershaus O., Meinel A., Holzgrabe U. Fatty acid composition analysis in polysorbate 80 with high performance liquid chromatography coupled to charged aerosol detection. Eur. J. Pharm. Biopharm. 2015;94:569–574. https://doi.org/10.1016/j.ejpb.2014.11.018

10. Seregin A.S., Orlova N.V., Askretkov A.D., Zybin D.I, Seregin Y.A. Quantification of polysorbate 80 in biopharmaceutical formulations implementing an optimized colorimetric approach. Fine Chem. Tech. 2020;15(3):70–77. https://doi.org/10.32362/2410-6593-2020-15-3-70-77

11. Savjani N., Babcock E., Khor H.K., Raghani A. Use of ferric thiocyanate derivatization for quantification of polysorbate 80 in high concentration protein formulations. Talanta. 2014;130:542–546. https://doi.org/10.1016/j.talanta.2014.07.052

12. Dwivedi M., Buske J., Haemmerling F., Blech M., Garidel P. Acidic and alkaline hydrolysis of polysorbates under aqueous conditions: Towards understanding polysorbate degradation in biopharmaceutical formulations. Eur. J. Pharm. Sci. 2020;144:105211. https://doi.org/10.1016/j.ejps.2019.105211

13. Kishore R.S.K., Pappenberger A., Dauphin I.B., Ross A., Buergi B., Staempfli A., Mahler H.C. Degradation of Polysorbates 20 and 80: Studies on Thermal Autoxidation and Hydrolysis. J. Pharm. Sci. 2011;100(2):721–731. https://doi.org/10.1002/jps.22290

14. Huang Z., Tu C., Liu H., Wang L., Zhu Z., Watanabe I. The composition analysis of free and bonded fatty acids in Polysorbate 80 by on-line two-step pyrolytic methylation-gas chromatography. J. Microchem. 2020;159:105342. https://doi.org/10.1016/j.microc.2020.105342

15. Shende N., Karale A., Bhagade S. Evaluation of a sensitive GC-MS method to detect polysorbate 80 in vaccine preparation. J. Pharm. Biomed. Anal. 2020;183:113126. https://doi.org/10.1016/j.jpba.2020.113126

16. Mondal B., Kote M., Lunagariya C., Patel M. Development of a simple high performance liquid chromatography(HPLC)/evaporative light scattering detector (ELSD) method todetermine Polysorbate 80 in a pharmaceutical formulation. Saudi Pharma. J. 2020;28(3):325–328. https://doi.org/10.1016/j.jsps.2020.01.012

17. Puschmann J., Evers D.H., Muller-Goymann C.C., Herbig M.E. Development of a Design of Experiments optimized method for quantification of polysorbate 80 based on oleic acid using UHPLC-MS. J. Chromatogr. A. 2019;1599:136–143. https://doi.org/10.1016/j.chroma.2019.04.015

18. Wang Z., Wang Y., Tie C., Zhang J. A fast strategy for profiling and identifying pharmaceutic excipient polysorbates by ultra-high performance liquid chromatography coupled with high-resolution mass spectrometry. J. Chromatogr. A. 2020;1609:460450. https://doi.org/10.1016/j.chroma.2019.460450

19. Tomlinson A., Demeule B., Lin B., Yadav S. Polysorbate 20 Degradation in Biopharmaceutical Formulations: Quantification of Free Fatty Acids, Characterization of Particulates, and Insights into the Degradation Mechanism. Mol. Pharmaceutics. 2015;12(11):3805–3815. https://doi.org/10.1021/acs.molpharmaceut.5b00311

20. Oszi Z., Petho G. Quantitative determination of polysorbate 20 in nasal pharmaceutical preparations by highperformance liquid chromatography. J. Pharm. Biomed. Anal. 1998;18(4–5):715–720. https://doi.org/10.1016/S0731-7085(98)00265-9

21. Adamo M., Dick L.W., Qiu D. A simple reversed phase high-performance liquid chromatography method for polysorbate 80 quantitation in monoclonal antibody drug products. J. Chromatogr. B. 2010;878(21):1865–1970. https://doi.org/10.1016/j.jchromb.2010.04.039

22. Degterev M.B., Badaukayte R.A., Shukurov R.R. A development of high-throughput HPLC method for the polysorbate 80 quantitation in protein therapeutic products. J. Chromatogr. B. 2019;1133:121847. https://doi.org/10.1016/j.jchromb.2019.121847

23. Wei Z., Bilbulian S., Li J., Pandey R., O’Connor E., Casas-Finet J., Cash P.W. Universal method for the determination of nonionic surfactant content in the presence of protein. J. Sep. Sci. 2015;38(8):1318–1325. https://doi.org/10.1002/jssc.201400766

24. Degterev M.B. Method for measuring the quantity of Tween 80 using alkaline hydrolysis of a sample followed by highperformance liquid chromatography: Pat. WO2019117750. Publ. 20.06.2019.

25. Grokhovskii V.I., Bendryshev A.A., Shvets S.V., Orlov D.A., Vaganova O.A. Determination of polysorbates in biotech drugs. Razrabotka i registratsiya lekarstvennykh sredstv = Drug Development & Registration. 2017;2(19):160–165 (in Russ.).

26. Hu M., Niculescu M., Zhang X.M., Hui A. Highperformance liquid chromatographic determination of poly-sorbate 80 in pharm aceutical suspensions. J. Chromatogr. A. 2003;984(2):233–236. https://doi.org/10.1016/s0021-9673(02)01849-6
