Development of a physiologically relevant method for nasal spray analysis using simulated nasal mucus

Objectives. Current methods for testing nasal spray dosage forms during development fail to fully assess the behavior of the drug following its release from the container, including subsequent distribution, retention, and permeability across the mucosal barrier. Existing in vitro models typically overlook the critical factor of drug interaction with nasal mucus, which substantially limits their predictive power and physiological relevance. The study set out to develop a physiologically based analytical method that addresses this gap by employing representative simulated nasal mucus compositions to evaluate the key performance parameters of the spray.

Methods. The pH of the investigated compositions was determined potentiometrically in accordance with the requirements of the 15th Russian State Pharmacopoeia, OFS.1.2.3.0032, using a pH meter (Econix-Expert, Russia) equipped with an ESK-10601 glass electrode (Izmeritelnaya Tekhnika, Russia). The dynamic viscosity of the compositions was measured using a Brookfield DV2T RV rotational viscometer (Brookfield, USA) with a thermostatically controlled measuring unit ofthe coaxial cylinder type within a temperature range of 25–37°C. The contact angle was determined by the sessile drop method using an EasyDrop Standard instrument (Krüss, Germany). The distribution of nasal sprays was evaluated with a silicone model of the human nasal cavity (Koken Co. Ltd., Japan).

Results. Representative simulated nasal mucus compositions were developed and characterized that reliably reproduce the key physicochemical and rheological properties of human nasal secretions under both normal and pathologically inflamed conditions. An experimental setup combining an anatomical silicone nasal cavity model with an applied layer of simulated nasal mucus was created and validated. The developed model permits quantitative assessment of key parameters, such as the distribution and coverage area of the drug substance upon contact with mucus of varying viscosity. As such, it provides a physiologically relevant platform for studying nasal sprays during dosage form development.

Conclusions. The proposed approach offers a valuable tool for optimizing the composition and design of nasal sprays, enabling comparative analysis under conditions that closely mimic physiological realities.

1. Eccles R., Meier C., Jawad M., Weinmüllner R., Grassauer A., Prieschl-Grassauer E. Efficacy and safety of an antiviral Iota-Carrageenan nasal spray: a randomized, double-blind, placebo-controlled exploratory study in volunteers with early symptoms of the common cold. Respir. Res. 2010;11(1):108. https://doi.org/10.1186/1465-9921-11-108

2. Weltzin R., Monath T.P. Intranasal antibody prophylaxis for protection against viral disease. Clin. Microbiol. Rev. 1999;12(3):383–393. https://doi.org/10.1128/cmr.12.3.383

3. Appasaheb P.S., ManoharS.D., BhanudasS.R. Areview on intranasal drug delivery system. J.Adv. Pharmacy Ed. Res. 2013;3(4):333–346.

4. Putheti R.R., Patil M.C., Obire O. Nasal Drug delivery in Pharmaceutical and biotechnology: present and future. e-Journal Sci. Technol. 2009;4(3):1–12.

5. Chavan P., Dhole S., Yadav M. Nasal drug delivery system: a review. World J. Pharm. Pharm. Sci. 2014;3(12):598–617.

6. Illum L. Nasal drug delivery: new developments and strategies. Drug Discov. Today. 2002;7(23):1184–1189. https://doi.org/10.1016/s1359-6446(02)02529-1

7. Nangare A.C., Kakade S., Bhosale A. Nasal Drug Delivery System: A Review. International Journal of Trend in Scientific Research and Development (IJTSRD). 2021;5(5):572–579.

8. Thorat S. Formulation and product development of nasal spray: an overview. Sch. J. Appl. Med. Sci. 2016:4(8D): 2976–2985. https://doi.org/10.36347/sjams.2016.v04i08.048

9. Privalova A.M., Gulyaeva N.V., Bukreeva T.V. Intranasal administration: a prospective drug delivery route to the brain. Neurochem. J. 2012;6(2):77–88. https://doi.org/10.1134/S1819712412020080 [Original Russian Text: Privalova A.M., Gulyaeva N.V., Bukreeva T.V. Intranasal administration: a prospective drug delivery route to the brain. Neirokhimiya. 2012;29(2):93 (in Russ.). https://elibrary.ru/oxycdx ]

10. Gulenkov A.S., Mizina P.G. Sprays – Pharmaceutical Development Design (Review). Voprosy obespecheniya kachestva lekarstvennykh sredstv= Journal of Pharmaceuticals Quality Assurance Issue. 2023;3(41):74–83 (in Russ.). https://doi.org/10.34907/JPQAI.2023.16.62.011

11. Marks D., Birkhoff M., Williams G. Intranasal Drug Delivery: An Interesting Past and a Promising Future. Farmatsevticheskie tekhnologii i upakovka = Pharmaceutical Technology and Packaging. 2015;5:70–77 (in Russ.).

12. Gribanova S.V., Yankova V.G., Gobyzov O.A., Ryabov M.N., Karpova A.S., Kedik S.A., Udyanskaya I.L., Grigorieva V.Yu., KrasnyukI.I.(Jr), SlonskayaT.K., ZhukovaA.A., SimonyanL.A. Comprehensive analysis of the spray parameters of nasal sprays containing antibiotics, anti-inflammatory and vasoconstrictive components. Voprosy prakticheskoi pediatrii = Clinical Practice in Pediatrics. 2023;18(3):75–82 (in Russ.). https://doi.org/10.20953/1817-7646-2023-3-75-82

13. DomninaY.M., Kedik S.A., SuslovV.V., Shnyak E.A. Rationale for the selection of auxiliary components for the naltrexone hydrochloride nasal spray. Razrabotka i registratsiya lekarstvennykh sredstv = Drug Development & Registration. 2018;4:73–77 (in Russ.). https://elibrary.ru/yorwap

14. Karpova A.S., Kochkina Y.V., Kedik S.A. The Antiviral Activity Study of Complex Drug with Aminocapronic Acid for Prevention of Influenza and ARVI. Razrabotka i registratsiya lekarstvennykh sredstv = Drug Development & Registration. 2019;8(2):22–26 (in Russ.). https://doi.org/10.33380/2305-2066-2019-8-2-22-26

15. Vlasenko Y.V. In vitro permeability study of nasal medical product for systemic action. Voprosy biologicheskoi, meditsinskoi i farmatsevticheskoi khimii = Problems of Biological, Medical and Pharmaceutical Chemistry. 2024;27(5):16–22 (in Russ.). https://doi.org/10.29296/25877313-2024-05-02

16. Rogers D.F. Physiology of airway mucus secretion and pathophysiology of hypersecretion. Respir. Care. 2007;52(9): 1134–1146. https://doi.org/10.4187/respcare.07521134

17. Owens D.K., Wendt R.C. Estimation of the surface free energy of polymers. J. Appl. Polym. Sci. 1969;13(8):1741–1747. https://doi.org/10.1002/app.1969.070130815

18. Masiuk T., Kadakia P., WangZ. Development of aphysiologically relevant dripping analytical method using simulated nasal mucus for nasal spray formulation analysis. J. Pharm. Anal. 2016;6(5):283–291. https://doi.org/10.1016/j.jpha.2016.05.003

19. Ilin V.K., Orlov O.I., Kiryukhina N.V., Morozova Yu.A. Artificial Nasal Secret: RF Pat. 2800117. Publ. 18.07.2023.

20. Lai S. K., Wang Y.Y., Wirtz D., Hanes J. Micro- and macrorheology of mucus. Adv. Drug Deliv. Rev. 2009;61(2): 86–100. https://doi.org/10.1016/j.addr.2008.09.012

21. Artem’eva-Karelova A.V. The rheologic characteristics of nasal secretion. Vestnik otorinolaringologii = Russian Bulletin of Otorhinolaryngology. 2014;3:76–79 (in Russ.).

22. Castile J., Cheng Y., Simmons B., Perelman M., Smith A., Watts P. Development of in vitro models to demonstrate the ability of PecSys®, an in situ nasal gelling technology, to reduce nasal run-off and drip. Drug Dev. Ind. Pharm. 2013;39(5): 816–824. https://doi.org/10.3109/03639045.2012.707210
