Development, characterization, and stability assessment of a lyophilized Eculizumab formulation for use as a reference material

Objectives. The study set out to develop a stable lyophilized formulation of the monoclonal antibody Eculizumab, comprehensively characterize the resulting material, and assess its stability for qualifying it as a reference material. This involved developing a matching placebo formulation, determining the optimal lyophilization conditions, and conducting a rigorous stability study.

Methods. In the development of the formulation and lyophilization conditions for Eculizumab, we tested various buffer systems and cryoprotectants. The residual moisture content in the resulting lyophilized samples was determined by Karl Fischer titration. Peptide mapping was performed using reversed-phase high-performance liquid chromatography (RP-HPLC) following enzymatic hydrolysis with trypsin. The structural, physicochemical, and biological properties were analyzed using various analytical methods, including RP-HPLC, high-performance liquid chromatography mass spectrometry, capillary sodium dodecyl sulfate electrophoresis, size-exclusion high-performance liquid chromatography, and enzyme-linked immunosorbent assay.

Results. A placebo solution for lyophilization of Eculizumab was selected with the following composition: 20 mM sodium phosphate, 4% trehalose, 0.2% polysorbate 80, pH 7.0. The results demonstrated a high degree of similarity between the candidate reference material and Eculizumab EU. Stability studies under storage conditions at 2–8°C demonstrated the material’s stability for one year, with control points at 3, 6, 9, and 12 months.

Conclusions. The absence of any effect of the drying process on the primary and spatial structure, post-translational modifications, content of related impurities, composition of isoforms, and specific activity was confirmed. Furthermore, stability studies demonstrated no significant changes in protein quality during storage at 2–8°C for at least 12 months, which represents the entire available data period at the time of manuscript preparation. The results indicate that the developed lyophilized material is a viable candidate for an international reference material, although its official qualification would require additional collaborative trials and long-term stability data.

1. Sheridan M., Massich M., Ashourian N. Biosimilars: From production to patient. J. Infus. Nurs. 2024;47(1):19–29. https://doi.org/10.1097/NAN.0000000000000528

2. An Z., Forrest G., Moore R., Cukan M., Haytko P., Huang L., Strohl W. IgG2m4, an engineered antibody isotype with reduced Fc function. mAbs. 2009;1(6):572–579. https://doi.org/10.4161/mabs.1.6.10185

3. Thomas T.C., Rollins S.A., Rother R.P., Giannoni M.A., Hartman S.L., Elliott E.A., Nye S.H., Matis L.A., Squinto S.P., Evans M.J. Inhibition of complement activity by humanized anti-C5 antibody and singlechain Fv. Mol. Immunol. 1996;33(17–18):1389–1401. https://doi.org/10.1016/S0161-5890(96)00078-8

4. Rother R.P., Rollins S.A., Mojcik C.F., Brodsky R.A., Bell L. Discovery and development of the complement inhibitor eculizumab for the treatment of paroxysmal nocturnal hemoglobinuria. Nat. Biotechnol. 2007;25:(11):1256–1264. https://doi.org/10.1038/nbt1344

5. Wijnsma K.L., ter Heine R., Moes D.J.A.R., Langemeijer S., Schols S.E.M., Volokhina E.B., van den Heuvel L.P., Wetzels F.M., van de Kar N.C.A.J., Brüggemann R.J. Pharmacology, pharmacokinetics and pharmacodynamics of eculizumab, and possibilities for an individualized approach to eculizumab. Clin. Pharmacokinet. 2019;58(7):859–874. https://doi.org/10.1007/s40262-019-00742-8

6. Hillmen P., Hall C., Marsh J.C., Elebute M., Bombara M.P., Petro B.E., et al. Effect of eculizumab on hemolysis and transfusion requirements in patients with paroxysmal nocturnal hemoglobinuria. N. Engl. J. Med. 2004;350(6): 552–559. https://doi.org/10.1056/NEJMoa031688

7. Brodsky R.A., Young N.S., Antonioli E., Risitano A.M., Schrezenmeier H., Schubert J., et al. Multicenter phase 3 study of the complement inhibitor eculizumab for the treatment of patients with paroxysmal nocturnal hemoglobinuria. Blood. 2008;111(4): 1840–1847. https://doi.org/10.1182/blood-2007-06-094136

8. Luzzatto L., Risitano A.M., Notaro R. Paroxysmal nocturnal hemoglobinuria and eculizumab. Haematologica. 2010;95(4): 523–526. https://doi.org/10.3324/haematol.2009.017848

9. Rondeau E., Cataland S.R. Al-Dakkak I., Miller B., Webb N.J.A., Landau D. Eculizumab safety: Five-year experience from the global atypical hemolytic uremic syndrome registry. Kidney Int. Rep. 2019;4(11): 1568–1576. https://doi.org/10.1016/j.ekir.2019.07.016

10. Cordero L., Cavero T., Gutiérrez E., Trujillo H., Sandino J., Auñón P., Rivero M., Morales E. Rational use of eculizumab in secondary atypical hemolytic uremic syndrome. Front. Immunol. 2023;14:1310469. https://doi.org/10.3389/fimmu.2023.1310469

11. Zuber J., Fakhouri F., Roumenina L.T., Loirat C., Frémeaux-Bacchi V. Use of eculizumab for atypical haemolytic uraemic syndrome and C3 glomerulopathies. Nat. Rev. Nephrol. 2012;8(11):643–657. https://doi.org/10.1038/nrneph.2012.214

12. Wijnsma K.L., Duineveld C., Wetzels J.F.M., van de Kar N.C.A.J. Eculizumab in atypical hemolytic uremic syndrome: Strategies toward restrictive use. Pediatr. Nephrol. 2019;34(12): 2261–2277. https://doi.org/10.1007/s00467-018-4091-3

13. Thomas K., Ananthula A., Lopez-Flores R., del Toro A., Chapple A.G., Loch M. The use of eculizumab for the treatment of atypical hemolytic uremic syndrome in an academic hematology center. Permanente J. 2023;27(2):22.073. https://doi.org/10.7812/TPP/22.073

14. Levy A.R., Chen P., Johnston K., Wang Y., Popoff E., Tomazos I. Quantifying the economic effects of ravulizumab versus eculizumab treatment in patients with atypical hemolytic uremic syndrome. J. Med. Econ. 2022;25(1): 249–259. https://doi.org/10.1080/13696998.2022.2027706

15. Howard J.F.Jr., Karam C., Yountz M., O’Brien F.L., Mozaffar T. Long-term efficacy of eculizumab in refractory generalized myasthenia gravis: Responder analyses. Ann. Clin. Transl. Neurol. 2021;8(7):1398–1407. https://doi.org/10.1002/acn3.51376

16. Patel A.D., Shah A., Avila J.D. A new era in the treatment of myasthenia gravis: Six new medications in the last 6 years. Curr. Treat. Options Neurol. 2024;26(2):79–96. https://doi.org/10.1007/s11940-024-00783-w

17. Brandsema J.F., Ginsberg M., Hoshino H., Mimaki M., Nagata S., Rao V., Ruzhansky K., Suresh N., Tiongson E., Yamanouchi H., Frick G., Hicks E., Liao S., Howard J. A phase 3, open-label, multicenter study to evaluate eculizumab in adolescents with refractory generalized myasthenia gravis. Neurology. 2023;100(17_supplement_2):1926. https://doi.org/10.1212/WNL.0000000000202200

18. Nabizadeh F., Moghadasi A.N. Eculizumab in the treatment of neuromyelitis optica spectrum disorder. Curr. J. Neurol. 2023;22(2):140–143. https://doi.org/10.18502/cjn.v22i2.13342

19. Enriquez M., Rosenthal S., Kammeyer R., Piquet A., Bennett J., McLedon L.A. Efficacy of eculizumab in acute refractory pediatric neuromyelitis optica: A case report. Neurology. 2024;102(7_supplement_1):4052. https://doi.org/10.1212/WNL.0000000000205538

20. Pittock S.J., Lennon V.A., McKeon A., Mandrekar J., Weinshenker B.G., Lucchinetti C.F., et al. Eculizumab in AQP4-IgG-positive relapsing neuromyelitis optica spectrum disorders: An open-label pilot study. Lancet Neurol. 2013;12(6): 554–562. https://doi.org/10.1016/S1474-4422(13)70076-0

21. Digala L., Katyal N., Narula N., Govindarajan R. Eculizumab in the treatment of aquaporin-4 seronegative neuromyelitis optica spectrum disorder: A case report. Front. Neurol. 2021;12:660741. https://doi.org/10.3389/fneur.2021.660741

22. Gervasi V., Dall Agnol R., Cullen S., McCoy T., Vucen S., Crean A. Parenteral protein formulations: An overview of approved products within the European Union. Eur. J. Pharm. Biopharm. 2018;131:8–24. https://doi.org/10.1016/j.ejpb.2018.07.011

23. Zybin D.I., Seregin A.S., Askretkov A.D., Orlova N.V., Seregin Y.A., Prostyakova A.I., Kapustin D.V. Development and validation of a method for the determination of the specific activity of recombinant monoclonal antibody eculizumab. Tonk. Khim. Tekhnol. = Fine Chem. Technol. 2020:15(2): 77–85. https://doi.org/10.32362/2410-6593-2020-15-2-77-85

24. Thakral S., Sonje J., Munjal B., Suryanarayanan R. Stabilizers and their interaction with formulation components in frozen and freeze-dried protein formulations. Adv. Drug Deliv. Rev. 2021;173:1–19. https://doi.org/10.1016/j.addr.2021.03.003

25. Carpenter J.F., Chang B.S., Garzon-Rodriguez W., Randolph T.W. Rational design of stable lyophilized protein formulations: Theory and practice. In: Rational Design of Stable Protein Formulations. Springer. 2002;109–133. https://doi.org/10.1007/978-1-4615-0557-0_5

26. Zybin D.I., Zhuchenko M.A., Rassulin Y.Y., et al. Comparative study of the stability of eculizumab biosimilar and the original drug under extreme pH, oxidative stress, and UV irradiation conditions. Pharm. Chem. J. 2021:55(7);732–739. https://doi.org/10.1007/s11094-021-02485-y

27. Matejtschuk P., Bird C., Ezeajughi E., MacLellan-Gibson K., Wadhwa M. Impact of formulation choices on the freeze-drying of an interleukin-6 reference material. Front. Mol. Biosci. 2022;9:868460. https://doi.org/10.3389/fmolb.2022.868460

28. Bjelošević M., Pobirk A.Z., Planinšek O., Grabnar P.A. Excipients in freeze-dried biopharmaceuticals: Contributions toward formulation stability and lyophilisation cycle optimisation, Int. J. Pharm. 2020;583:119029. https://doi.org/10.1016/j.ijpharm.2020.119029

29. Khawli L.A., Goswami S., Hutchinson R., Kwong Z.W. Charge variants in IgG1: Isolation, characterization, in vitro binding properties and pharmacokinetics in rats. mAbs. 2010;2(6):613–624. https://doi.org/10.4161/mabs.2.6.13333

30. Tak M., Jeong H., Yun J., Kim J., Kim S., Lee Y., Park S.J. In-use stability of SB12 (eculizumab, Soliris biosimilar) diluted in saline and dextrose infusion solution after an extended storage period. Drugs R&D. 2023:23(4):363–375. https://doi.org/10.1007/s40268-023-00433-7
